PA2006IV 6 Zones Mixing Amplifier(60W)
左滚动
  • PA2006IV 6 Zones Mixing Amplifier(60W)
  • PA2006IV 6 Zones Mixing Amplifier(60W)
  • PA2006IV 6 Zones Mixing Amplifier(60W)
  • PA2006IV 6 Zones Mixing Amplifier(60W)
  • PA2006IV 6 Zones Mixing Amplifier(60W)
右滚动
  • PA2006IV 6 Zones Mixing Amplifier(60W)
● Two microphone inputs, three Line inputs, and one Line output for link.
● Transform the output into 6 zones.
● Muting function.
● Individual volume control.
● Bass and treble tone control.
● A five-element LED level meter is provided for the quick and easy visual monitoring of sound level.
● The protection and alarm in case of output short-circuit.

Description
PA2006PIV is 6 zone mixer amplifier with new circuit design and its rated power is 60W. It has 2 microphone inputs and 3 aux inputs. Mic1 has priority over other inputs.Individual gain controls are provided for Microphone and aux; bass and treble controls and master volume control are available.
Its 6 zone selectors provide a direct control interface to users for easy control and zone paging. The alarm button will automatically activate the pre-recorded message 3 over other aux inputs.
Extensive protection are provided for indicators from short-circuit, overload, high temp, AC fuse and DC voltage .Intelligent variable frequency and cooling system to ensure extreme quite sound system.Mute function, easy to override with the priority broadcast; 100V transmission voltage; bass and treble tone can be controlled individually.
Combine pre-amp, power –amp and zoning, suit for mid and small public address system, like super market, restaurant,and coffee shop.

Specifications

   Model

PA2006PIV

   Rated output

60W

 Output regulation

Less than 3dB

  Speaker output

100V

AUX output

1V

Input Sensitivity

Mic1,2,    3mV  unbalanced

Line 1,2,3,  300mV  unbalanced

 Frequency response

65Hz-20kHz (±3dB)

  The ratio of signal to noise ratio
Distortion

Less than 0.3%  at 1kHz , 1/3 rated power



Mic1 and 2  :   Bigger than 80dB



Line 1、2 and 3  Bigger than 80dB

Tone

Bass :  ±10dB at 100Hz

Treble: ±10dB at 10kHz

     Protection

AC fuse; DC voltage; overload; short-circuit.

  Muting function

Mic1 overrides other input signals with

0 ~ -30dB attenuation

      Power requirements

AC 220-240V/50-60Hz

      Power  consumption

120W

    Dimensions

485×340×88mm

   Gross weight

8.5kg

    Net weight

7.2kg
