AXT8789II Network Public Address Center
左滚动
  • AXT8789II Network Public Address Center
右滚动
  • AXT8789II Network Public Address Center
IP based network system


17’’ true color touch screen, east for use


Industrial circuit board for stable running


Standard 19’’ design for rack mounting


Keys are needed to turn on the console, ensure the operation system


Module design to meet different project requirement


Support online software updating

Description:

The network public address center AXT8789II is compatible with terminals with various functions, including player terminals, VOD terminals, paging terminals and one-button emergency calling terminals etc. The device is composed of a player, a zoning mechanism, a timer and an equalizer, in addition it also provides powerful audio matrix function.

The network public address system is applicable to airports, wharves, college towns, schools, large gatherings (such as the Expo Park), gymnasium, industrial parks, parks, rail transit and express ways, etc.

Specification:

Model

AXT8789II

Screen size

17" LCD

Operating Manner

Touchscreen

Working environment

Ambient temperature:  5-35ºC; Relative humidity:  ≤75%; Barometric pressure:  86-106kpa

Load capacity of timing power source

Current at single channel:  2A

SNR of system audio signal

LINE:   >70dB;  MIC:   >60dB

Distortion of system audio signal

1kHz<0.5%

Standard input voltage level of system audio signal

LINE : 300mV±20mV;  MIC :10mV±2mV

Standard output voltage level of system audio signal

0dBV

Manner of power output

Fixed resistance

Output power without distortion

10W

Power consumption of the device

AC 220-240V/50-60Hz/150W

Dimensions (L×W×H mm)

483×308×445

Gross weight

33.7kg

Net Weight

24.5kg

System software

Software package of network public address system   Copyright reserved. Reproduction or counterfeit is prohibited.
