- PA120UB
- PA120UB Mini Digital Mixer Amplifier with USB & Bluetooth
● 2 MIC inputs, 2 EMC inputs, 2 line inputs, 1 line output.
● Speaker output of 100V or 70V & 4 -16 Ω.
● Support infrared remote control.
● With priority function, priority is EMC/MIC1>AUX1/AUX2/MIC2.
● With master volume control, individual volume control of MIC & Line, treble and bass volume control.
Description:
PA120UB is 1.5U designed Mini Digital amplifier with USB/FM and Bluetooth. The Speaker output is 70V/100V and 4-16Ω available, 3 Aux input, Min1 is 6.3mm jack in front panel and Mic2 is XLR in rear panel, Phantom power available for Mic2. Individual volulme control for each Mic and Aux, also provide Bass and Treble control. what's more, it also has EMC singal input for emgerency situation.
Specification:
|
Model |
PA55UB PA120UB |
PA55UB PA120UB |
|
Power Supply |
~110V-240V/50/60Hz |
~220V/50/60Hz |
|
MIC1 input sensitivity |
8mV±1mV |
10mV±1mV |
|
MIC2 input sensitivity |
8mV±1mV |
10mV±1mV |
|
AUX1 input sensitivity |
360mV±20mV |
|
|
AUX2 input sensitivity |
360mV±20mV |
|
|
EMC input sensitivity |
360mV±20mV |
|
|
MIC frequency response |
180Hz～10kHz（±3dB） |
|
|
AUX frequency response |
70Hz～16kHz（±3dB） |
|
|
Noise |
<5mV (4Ω load output port) |
<10mV |
|
Distortion |
<1% 1KHz |
|
|
Treble adjustment |
10dB（±2） |
|
|
Bass adjustment |
10dB（±2） |
|
|
Rated power supply |
AC220V |
|
|
Speaker outputs |
35W 4Ω, AC220V |
120W 4Ω, AC220V |
|
Interface output voltage |
70V, 100V (Constant voltage output) |
|
|
Machine size(L×W×H) |
247*198*66mm |
|
|
Packing size |
343*302*121mm (1PC) |
|
|
Maximum packing size |
630*355*283mm (4PCS) |
|
|
Net Weight |
2.5kg |
3Kg |
|
Gross Weight |
3.2Kg (1PC) |
3.7Kg (1PC) |
