- PA635U 6 Zones 350W 4 Mic 3 Aux Mixing Amplifier
● Infrared remote control to control MP3/TUNER/BT, which includes modes switches, program selection, volume adjustment, repeat mode, EQ mode and USB/SD switches.
● LED display indicates volume, playing status, program number, etc.
● 4 MIC inputs, 3 AUX inputs, and 1 AUX output.
● 4-16 Ω rated output.
● 6-zone selector, individual volume control and output level indication for each zone output.
● Mute function for priority input.
● Treble and Bass control.
● Chime with priority output.
● 5-unit LED indicates monitoring volume output in each zone.
● Output short circuit protection and caution
Description
This product is a mixer amplifier with MP3 player, FM tuner, and Bluetooth. It supports infrared remote control for mode switching, program selection, volume control, EQ mode selection, and source selection. With an LED display screen, it can show the volume level, playing status, program number, etc. It provides 4 microphone inputs, 3 auxiliary inputs and 1 auxiliary output. Also, with a zone selector, it can realize separate volume control for 6 zones.
Specifications
|
Model |
PA606U |
PA612U |
PA625U |
PA635U |
|
Rated Output |
60W |
120W |
250W |
350W |
|
Output regulation |
≤3dB (from full load to off-load) |
|||
|
Input sensitivity |
Microphone : ≤3mV (unbalanced) |
|||
|
AUX: ≤300mV (unbalanced) |
||||
|
Frequency response |
80Hz-16KHz (±3dB) |
|||
|
Distortion |
≤1% （1KHz, normal operating status） |
|||
|
S/N Ratio |
AUX: ≥74dB |
|||
|
Tone |
Bass: ±10dB（at 100Hz） |
|||
|
Treble: ±10dB（at 10kHz） |
||||
|
Protection |
DC voltage; overload; short-circuit. |
|||
|
Mute |
Input signals from MIC 1 override other input signals. |
|||
|
Power supply |
AC 220V/50Hz |
|||
|
Power Consumption |
120W |
250W |
500W |
650W |
|
Outer Packing Size(mm) |
(L×W×H) 555×455×185 |
|||
|
Unit Size (mm) |
(L×W×H) 484×355×88 |
|||
|
Gross Weight |
11.7kg |
13.5kg |
16kg |
17kg |
|
Net Weight |
9.7kg |
11.5kg |
14kg |
15kg |
